Product Details:
Payment & Shipping Terms:
|
| Model: | High Accuracy Model | Name: | Metal Detector |
|---|---|---|---|
| HS Code: | 85437091 | Alarm: | Pilot Lamp Flash With Alarm And Conveyor Stop |
| Auto Rejection: | By Customer Optional |
Basic Model Metal detector JL-MD series
Characteristics:
1. Simple structure design for foods product inspection.
2.Phase discriminating technology that can effectively refrain product effect;
3.The DSP technology and leading intelligent algorithm improve the detection sensitivity.
5. Be able to detect out metals like iron, stainless steel, copper, gold, silver and aluminum, etc.
6.LCD display, Chinese&English operation menu;
7.Auto-setting function, automatically setting suitable working parameters according to different products;
8. Memory function support for 15 kinds of different products registering.
9, Support Password setting.
10 Simple conveyor structure, disassemble and assemble more convenient;
11 Special design of conveyor belt to avoid deviation;
12. Made of stainless steel, fairly good dustproof, waterproof ability. Easy to be clearned.
Application:
Suitable for metal contaminants detection in foods, such bread, cookies, nuts, vegetables, Chemical Raw Materials, Toys. Detecting all metal contaminants in packaged and non-packaged food, including ferrous metal (Fe), non-ferrous metals (Copper, Aluminum etc.) and Stainless Steel.
Technical Parameter :
| Model: | JL-MD-30 series/ 40 series | JL-MD50 series / 60 series |
| Detection tunnel width: | 300mm/400mm | 500mm/600mm |
| Detection tunnel height: | 80mm-200mm | 80mm-300mm |
| Conveyor belt width : | 260mm/360mm | 460mm/560mm |
| Max capacity: | 10kgs | 30kgs |
| Motor output : | 150w | 200w |
| Speed(m/min): | 25m/m | |
| Display/Operation Panel | LCD display with button design | |
| Display/Operation Language |
English/Chinese/Spanish (Spanish Language by customer choose) |
|
| Alarm method: | Alarm and lamp flash to stop transfer | |
| Auto reject: | auto pusher/swing arm /air blast/flapper (by customer’s optional) | |
| Conveyor belt: | Food Grade PU belt (Modular Conveyor by customer’s optional) | |
| Power: | AC110V/220V 50-60hz | |
| Net Weight:200-250kgs | 200kgs | 300kgs |
Detection sensitivity:
| Model size | Tunnel width | Tunnel height |
Detection sensitivity(Φ) (Test by metal test card on the conveyor belt only) |
| 3010,4010 | 300MM,400MM | 100MM | Fe≧0.8mm;Non-fe≧1.2mm;Sus≧1.5mm |
| 3012,4012 | 300MM.400MM | 120MM | Fe≧1.0mm; Non-fe≧1.2mm;Sus≧1.5mm |
| 3015,4015 | 300MM.400MM | 150MM | Fe≧1.0mm;Non-fe≧1.5mm;Sus≧2.0mm |
| 3020,4020 | 300MM.400MM | 200MM | Fe≧1.2mm;Non-fe≧2.0mm;Sus≧2.5mm |
| Model | Tunnel width | Tunnel height | Detection sensitivity(Φ) |
| 5010,6010 | 500MM,600MM | 100MM | Fe≧0.8mm;Non-fe≧1.2mm;Sus≧1.5mm |
| 5012,6012 | 500MM,600MM | 120MM | Fe≧1.0mm; Non-fe≧1.2mm;Sus≧1.5mm |
| 5015,6015 | 500MM,600MM | 150MM | Fe≧1.0mm;Non-fe≧1.5mm;Sus≧2.0mm |
| 6020,6020 | 500MM,600MM | 200MM | Fe≧1.2mm;Non-fe≧2.0mm;Sus≧2.5mm |
