| Model: | Auto Conveyor Model | Detection Head: | Double Head |
|---|---|---|---|
| Detection Width: | 600mm | Detection Height: | From 80-180mm By Customer's Optional |
| Name: | Needle Detector,metal Detectors | HS Code: | 85437091 |
| Model: | High Accuracy Model | Alarm: | Pilot Lamp Flash With Alarm And Conveyor Stop |
| Auto Rejection: | By Customer Optional | ||
| High Light: | needle detector,metal detector,industrial metal detectors |
||
needle detector, metal detector, needle detectors, industrial metal detector, automatic metal detector, metal detector machiner, metal detector equipment, tunnel metal detector,belt metal detector,garment needle detector,garment metal detector,apparel needle detector,sock metal detector,sock needle detector,shoes metal detector,shoes needle detector,toy metal detector,toy needle detector,textile metal detector,textile needle detector,cloth metal detector,cloth needle detector,needle detection machine,metal detection machine,needle check,metal check,check needle,check metal,find metal,find needle,digital metal detector, electronic metal detector,broken needle
Double head type needle detector machine JC-6002
【Main features】
1. ABS plastic shell.
2. Double detection head design. make sure there are no any product miss detection
3. Cycled,9 pairs of sensor, excellent anti-disturbance performance.
4. Based on LED bar displayed control panel.
5. Smart auto counter. Count the alarm and pass numbers automatically.
6. Hi accuracy detection locating technology, LED indication for alarm location remind.
7. Alarm functions can be divided into three types, buzzer sound, lamplight flash and conveyor stop or belt return.
8. Optional conveying mode after alarm ;Optional automatical restart.
9. Reliability mechanical frame design, Hi stable during detection.
10. Designed for universal AC power supply, switch power supply.
【Range of Application】
It can be used to detect underwear, shirts, knitted sweaters, garments, shoes, socks, toys, carton, chemical, rubber, plastic, aluminum foil and others small packaged products.
【SPECIFICATIONS】
| Model: | JC-6002(double detection head model) |
| Detection tunnel width: | 600mm |
| Detection tunnel height: | 80mm/100mm/120mm/150mm/200mm/250mm/300mm/ |
| Conveyor belt width : | 570mm |
| Max capacity: | 20kgs |
| Motor output : | 200W |
| Speed(m/min): | 25m/m |
| Display/Operation Panel | LED display with button design |
| Display/Operation Language | English/Chinese |
| Alarm method: | Alarm and lamp flash to stop transfer |
| Conveyor belt: | Flat PVC belt |
| Power: | AC110V/220V 50-60hz |
| Net Weight:200-250kgs | 250kgs |
【Series Standard】
| Model | Tunnel width | Tunnel height | Detection sensitivity |
| JC6002/80 | 600MM | 80MM | Fe, Steel ball≧0.8mm |
| JC-6002/100 | 600MM | 100MM | Fe, Steel ball≧0.8mm |
| JC-6002/150 | 600MM | 150MM | Fe, Steel ball≧1.0mm |
| JC-6002/200 | 600MM | 200MM | Fe, Steel ball≧1.2mm |
| JC-6002/300 | 600MM | 300MM | Fe, Steel ball≧2.0mm |
| JC-6002/450 | 600MM | 450MM | Fe, Steel ball≧3.0mm |
