Product Details:
Payment & Shipping Terms:
|
| Model: | Conveyor Metal Detector | Name: | Needle Detector |
|---|---|---|---|
| Detection Height: | From 80mm-200mm | Detection Width: | 600mm |
| HS Code: | 85437091 | Model: | High Accuracy Model |
| Alarm: | Pilot Lamp Flash With Alarm And Conveyor Stop | Auto Rejection: | By Customer Optional |
Automatic conveyor type
【Range of Application】
It can be used to detect underwear, shirts, knitted sweaters, down and feather garments, shoes,scoks, beddings as well as plush medium and small toys.
【Main features】
1. ABS plastic shell.
2. Cycled,9 pairs of scnsor,excellentanti-disturbance performance.
3. Based on LED bar displayed control panel.
4.. Smart counter.
5.. Hi accuracy detection locating technology,LED indication.
6..Alarm functions can be divided into three types, saying sound, lamplight and frequency display.
7.Optional conveying mode after alarm ;Optional automatical restart.
8..Reliability mechanical frame design,Hi stable during detection.
9.Designed for universal AC power supply,switch power supply.
【SPECIFICATIONS】
▲ Model: JLC-600/100MM
▲ Detection method: Magnetic induction
▲ Detection sensitivity: 0.8mm steel to samll scissors
▲ Detection adjustment: 10step
▲ Detection width: 600mm
▲ Alarm method: Buzzer,Lamp
▲ Belt speed: 32m/min(50HZ),40m/min(60HZ)
▲ Power source: AC200-240V 50-60HZ
▲ Rated output: Appr140W
▲ Dimension: 1650mm(L)*1050mm(W)*900mm(H)
▲ Weight: Appr220Kg
| Detection height | Detection Sensibility |
| 100mm | Fe or steel 0.8mm |
| 120mm | Fe or steel 1.0mm |
| 150mm | Fe or steel 1.2mm |
| 200mm | Fe or steel 1.5mm |
More info,metal detector,needle detector,needle metal detector,conveyor metal detector, pls refer http://www.bjtoptech.com
