Check weigher, check weighers, check weigher machine, weight sorting machine, weight sort machine, online check weigher, online weight sorting machine, weight checker, weight pick, conveyor check weigher
Features:
1. Strong stainless steel; Waterproof design.
2. High accurate loadcell; Based on advanced DSP technology.
3. Automatic weighing compensation and zero tracking.
4.100 products preset; Easy to edit and recall.
5. Quickly product shift and speed recall.
6.2000 sorting records.
7. Printer output ready(By optional)
8. Touch screen; Friendly operation interface.
Parameters:
Model: JL-500IXL
Detecting Range:0.5~20kg
Scale Interval :1.0g
Accuracy: ±2g
Detecting Speed(Max speed):40-50pcs/min
Belt speed:60m/min
Operation Screen: 7-inch Touch LCD Screen
Product Storage Quantity: 100 kinds
Rejecter Rejecter Optional:By roller auto pusher
Power Supply 220V (Optional)
Degree of Protection : IP30/IP54/IP66(by customer's optional)
Body Material Stainless Steel (SUS304)
| Model size |
160 |
230S |
230L |
300 |
|
| Weight capacity |
10~600g |
20~2000g |
20~2000g |
50~5000g |
|
| Mini scale |
0.05g |
0.1g |
0.1g |
0.2g |
|
| Best accuracy |
±0.1g |
±0.2g |
±0.2g |
±0.5g |
|
| Max speed |
200-250bag/min |
150-200bag/min |
100-150bag/min |
70-140bag/min |
|
|
Belt speed
(adjustable)
|
70m/min |
70m/min |
70m/min |
70m/min |
|
|
Max Size Product
(size limited)
|
W |
150mm |
220mm |
220mm |
290mm |
|
| L |
200mm |
250mm |
350mm |
400mm |
|
| Weight platform |
W |
160mm |
230mm |
230mm |
300mm |
|
| L |
280mm |
350mm |
450mm |
500mm |
|
| Mark |
3 Segment (Feed,Weigher,Auto Reject) |
|
| Display & Operation |
7 inch Touch screen with display |
| Language |
English and Chinese |
| Product memory |
100 kinds of product |
| Reject |
Air blast/Pusher/Flap-Arm |
| Voltage |
AC220V(by customer optional) |
| Frame material |
SUS304
|
