Free fall pipe metal detector JL-IMD/P150 for powdder product inspection

Good quality NEEDLE DETECTOR FOR GARMENT&TEXTILE for sales
Good quality NEEDLE DETECTOR FOR GARMENT&TEXTILE for sales
I'm Online Chat Now

Free fall pipe metal detector JL-IMD/P150 for powdder product inspection

China Free fall pipe metal detector JL-IMD/P150 for powdder product inspection supplier
Free fall pipe metal detector JL-IMD/P150 for powdder product inspection supplier Free fall pipe metal detector JL-IMD/P150 for powdder product inspection supplier Free fall pipe metal detector JL-IMD/P150 for powdder product inspection supplier Free fall pipe metal detector JL-IMD/P150 for powdder product inspection supplier Free fall pipe metal detector JL-IMD/P150 for powdder product inspection supplier Free fall pipe metal detector JL-IMD/P150 for powdder product inspection supplier

Large Image :  Free fall pipe metal detector JL-IMD/P150 for powdder product inspection

Product Details:

Place of Origin: Shanghai,China
Certification: CE
Model Number: JL-IMD/P150

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: 100
Packaging Details: standard export wooden case
Delivery Time: 15-20 working days
Payment Terms: by T/T
Supply Ability: 100000pcs
Detailed Product Description
Model: High Accuracy Model Pipe Diameter: 150mm
Name: Metal Detector,gravity Metla Detector,free Fall Metal Detectors HS Code: 85437091
Alarm: Pilot Lamp Flash With Alarm And Conveyor Stop Auto Rejection: By Customer Optional

High accuracy free fall pipe metal detector for powder product inspection



Free fall pipe metal detector JL-IMD/P150 for powdder product inspection



Appliacation:

Metal impurities detecting in food, pharaceutical, food ingredients, condiment, health care things, particle plastic and farinose particle etc.



Free fall pipe metal detector JL-IMD/P150 for powdder product inspection



Features:

1.Whole stainless steel structure with detecting head

2.Adopting advanced electric and mechanical designing technique.

3.Two channel DSP technology advance the high anti-interference ability. And suppress the effect of the products effectively, up to the best detecting condition

4.The signal is finished by digital circuit, it is simple to change, and reliable to use.

5.It able to detect all kinds of metal chips, such as the iron , stainless steel , copper , aluminium and lead ,etc.

6.Interactive interface, the liquid crystal of LCD display, Chinese and English menu ,as well as convenient operation.

7.Easy to clear,take off and assembel



Free fall pipe metal detector JL-IMD/P150 for powdder product inspection



Specification

Model: BT-IMD-P75/P100/P150 Vertical Free Fall Pipe Metal Detector
Detection Pipe diameter: 75mm/100mm/150mm
Infeed hopper Installed
Alarm method: Alarm and lamp flash
Auto reject: Automatically separator reject
Standard frame Installed according customer requirment
Display/Operation Panel LCD display with button design
Display/Operation Language English/Chinese/Spanish
(Spanish Language by customer choose)
Pressure Requirements: 0.5Mpa
Power: AC110V/220V, 50-60hz
Net Weight: 100kg-150kgs

Free fall pipe metal detector JL-IMD/P150 for powdder product inspection



Detection sensitivity:

Model Detection Pipe Detection sensitivity(Φ)
(Test by metal test card in the detection tube only)
BT-IMD-P75 75mm Fe>=0.6mm;Non-fe>=1.2mm;Sus>=1.5mm
BT-IMD-P100 100mm Fe>=0.8mm; Non-fe>=1.2mm;Sus>=1.5mm
BT-IMD-P150 150mm Fe>=1.0mm;Non-fe>=1.5mm;Sus>=2.0mm
